Printing Parameters
Nozzle Temperature: 340~380°C
Bed Temperature: 100~120°C
Chamber Temperature: 50–65°C or 90–120°C
Bed Modification: glue and Thickened PEI board
Active Cooling Fan: 0–100%
Layer Height: 0.2 mm
Shell Thickness: ≥ 0.8 mm
Print Speed: 30–60 mm/s
Note: Settings are based on a 0.4mm nozzle.
Description
Low Printing Temperature: Engineered with a low melting point for compatibility with mid-to-high temperature desktop 3D printers.
High Precision: Slow crystallization rate helps reduce thermal stress and deformation to guarantee exceptional dimensional accuracy.
High Strength & Toughness: Delivers robust mechanical properties, making it ideal for load-bearing and demanding end-use structural components.
Excellent Heat Resistance: Maintains high structural integrity and thermal stability under elevated operating temperatures.
Chemical & Creep Resistance: Offers superior protection against chemical degradation and long-term mechanical strain or deformation.
Flame Retardant: Formulated with inherent fire-retardant properties to meet strict safety standards in technical applications.
Technical Datasheet
Melt Temperature: ~306°C (ISO 11357)
Melt Flow Rate (MFR): 30~40g/10min¹ (ISO 1133)
Heat Deflection Temperature (HDT)²: 150°C (ISO 75)
Vicat Softening Temperature (VST)³: 158°C (ISO 306)
Density: 1.27 g/cm³ (ISO 1183)
Odor: Odorless
Solubility: Insoluble in water
Note: ¹ Test conditions: T= 380℃; m= 5kg. ² Test conditions: 0.45MPa; 120℃/h. ³ Test conditions: 10N; 120℃/h.
