DER K9™ PC FR

1 kg

1.75mm

Features

UL94 V-0 Flame Retardance (1.5mm)
High Flowability
Low Warping
High Heat Resistance
Superior Mechanical Strength

TDS

MSDS

Brochure

SKUs

Das K9™ PC FR ist ein schwer entflammbares PC-Material mit hoher Fließfähigkeit, geringem Verzug und UL94-V0-Einstufung.

Empfohlene Druckparameter

Düs temperatur	260 ~ 300℃
Betttemperatur	100 ~ 120℃
Bettenmodifikation	Klebeband oder Klebstoff
Aktiver Kühlventilator	0~50%%

Printing Parameters

Nozzle Temperature: 260–300°C

Bed Temperature: 100–120°C

Bed Modification: Tape or glue

Active Cooling Fan: 0–50%

Layer Height: 0.2 mm

Shell Thickness: ≥ 0.8 mm

Print Speed: ≤ 500 mm/s

Note: Settings are based on a 0.4mm nozzle.

Description

UL94 V-0 Flame Retardance (1.5mm): Complies with UL94 V-0 standards at 1.5mm thickness, offering superior flame resistance and self-extinguishing safety properties.

High Flowability: Excellent melt flow behavior allows smooth, rapid material extrusion for high-speed printing performance.

Low Warping: Low thermal shrinkage ensures excellent dimensional stability, minimizing edge lifting and distortion on large-scale prints.

High Heat Resistance: High thermal deflection and softening temperatures allow functional parts to perform reliably in elevated temperature environments.

Superior Mechanical Strength: Delivers robust mechanical properties and high structural integrity for demanding end-use applications.
