DAS K6™ PLA FR
Features
- UL94 V-0 Flame Retardance
- Exceptional Toughness & High Elongation
- Zero Warping & High Layer Adhesion
- Easy & Smooth Printability
- Eco-Friendly PLA Base
PLA FR ist ein fortschrittliches Filament, das einfach zu drucken ist und verbesserte Flammwidrigkeit und Zähigkeit aufweist. Es erfüllt die UL94-V0 Sicherheitsstandards und bietet überlegene Flammwidrigkeit, außergewöhnliche Haltbarkeit und hervorragende Druckqualität.
Empfohlene Druckparameter
| Düs temperatur | 200 ~ 240℃ |
| Betttemperatur | 35 ~ 55℃ |
| Bettmodifikation | Band oder Klebstoff |
| Aktiver Kühlventilator | EIN,50~100% |
| Schichthöhe | 0.2mm |
| Schalenstärke | ≥ 0.8mm |
| Druckgeschwindigkeit | ≤ 250mm/s |
Technisches Datenblatt (TDS)
| Materialeigenschaften | Typischer Wert | Prüfmethode |
|---|---|---|
| Schmelztemperatur | ~160℃ | ISO 11357 |
| Glasübergangstemperatur | ~60℃ | ISO 11357 |
| Schmelzflussrate (MFR)¹ | 12~17g/10min | ISO 1133 |
| Wärmeformbeständigkeit (HDT)² | 60℃ | ISO 75 |
| Vicat Erweichungstemperatur (VST)³ | 70℃ | ISO 306 |
| Dichte | 1.30~1.32g/cm³ | ISO 1183 |
| Geruch | Geruchlos | / |
| Löslichkeit | Unlöslich in Wasser | / |
Printing Parameters
Nozzle Temperature: 200–240°C
Bed Temperature: 35–55°C
Bed Modification: Tape or glue
Active Cooling Fan: ON, 50–100%
Layer Height: 0.2 mm
Shell Thickness: ≥ 0.8 mm
Print Speed: ≤ 250 mm/s
Note: Settings are based on a 0.4mm nozzle.
Description
UL94 V-0 Flame Retardance: Formulated with self-extinguishing additive technology to meet UL94 V-0 standards, making it highly suitable for electrical and high-safety industrial applications.
Exceptional Toughness & High Elongation: Exhibits enhanced impact resistance and high elongation at break compared to standard PLA, preventing brittle failure under mechanical stress.
Zero Warping & High Layer Adhesion: Low thermal contraction ensures dimensionally stable prints with excellent interlayer bonding to prevent delamination.
Easy & Smooth Printability: Maintains the effortless printing characteristics of standard PLA with consistent extrusion, high dimensional precision, and minimal stringing.
Eco-Friendly PLA Base: Utilizes bio-based, plant-derived PLA resin as the matrix material to provide a more sustainable, low-odor 3D printing solution.
Technical Datasheet
Melt Temperature: ~160°C (ISO 11357)
Glass Transition Temperature: ~60°C (ISO 11357)
Melt Flow Rate (MFR): 12–17 g/10min¹ (ISO 1133)
Heat Deflection Temperature (HDT): 60°C² (ISO 75)
Vicat Softening Temperature (VST): 70°C³ (ISO 306)
Density: 1.30–1.32 g/cm³ (ISO 1183)
Odor: Odorless
Solubility: Insoluble in water
Note: ¹ Test conditions: T= 190℃; m= 2.16kg. ² Test conditions: 0.45MPa; 120℃/h. ³ Test conditions: 10N; 120℃/h.
