DAS K8™ TPU AIR
Ein einzigartiges Filament mit variabler Dichte und Härte von 65A bis 86A. Durch Anpassen der Drucktemperatur kann der Schäumungseffekt gesteuert werden, wodurch leichte, weiche und sogar schwimmfähige Teile entstehen. Es ist ein innovatives Material, das eine Welt neuer Möglichkeiten eröffnet.
Empfohlene Druckparameter
| Düs temperatur | 190 ~ 250℃ |
| Betttemperatur | 30 ~ 55℃ |
| Bettmodifikation | PEI mattierte Platte |
| Aktiver Lüfter | AN, 50~100 |
| Schichthöhe | 0.2mm |
| Gehäusedicke | ≥ 0.8mm |
| Druckgeschwindigkeit | 30mm/s |
Printing Parameters
Nozzle Temperature: 200–250°C
Bed Temperature: 30–50°C
Bed Modification: Golden PEI board
Active Cooling Fan: ON, 50–100%
Layer Height: 0.2 mm
Shell Thickness: ≥ 0.8 mm
Print Speed: 100 mm/s (Non-foaming) / 45 mm/s (200% foaming)
Note: Settings are based on a 0.4mm nozzle.
Description
Active Foaming Technology: Temperature-controlled expansion allows you to adjust density and Shore hardness dynamically from 65A to 86A.
Ultra-Lightweight & Buoyant: Reduced material weight creates soft, low-density parts that can float in water.
Tactile Fabric Texture: Produces a unique, non-plastic surface feel resembling woven textiles for premium soft-goods.
Functional Zone Printing: Enables tuned stiffness, cushioning, and density variations within a single continuous print.
Technical Datasheet
Melt Flow Rate (MFR): 8–20 g/10min¹ (ISO 1133)
Heat Deflection Temperature (HDT): N/A² (ISO 75)
Vicat Softening Temperature (VST): N/A (ISO 306)
Density: 1.14 g/cm³ (Non-foaming) / 0.57 g/cm³ (200% foaming) (ISO 1183)
Hardness: 90A (Non-foaming) / 69A (200% foaming) (GB/T 531.1)
Resilience: 29% (Non-foaming) / 23.5% (200% foaming) (GB/T 1681-2009)
Odor: Odorless (Non-foaming) / Slight odor (200% foaming)
Solubility: Insoluble in water
Note: ¹ Test conditions: T= 190℃; m= 1.2kg. ² Test conditions: 0.45MPa; 130℃/h.
