Printing Parameters
Nozzle Temperature: 230–250°C
Bed Temperature: 80–100°C
Bed Modification: Tape or glue
Active Cooling Fan: 0–50%
Layer Height: 0.2 mm
Shell Thickness: ≥ 0.8 mm
Print Speed: 40–80 mm/s
Note: Settings are based on a 0.4mm nozzle.
Description
100% Limonene Soluble: Dissolves completely and cleanly in D-Limonene without damaging the primary model material.
Broad Support Compatibility: Specially formulated to adhere seamlessly to ABS, ASA, PC, and PA (Nylon) filaments during multi-material printing.
High Thermal Stability (HDT > 80°C): Maintains structural integrity inside heated chambers and prevents premature sagging or warping.
High Impact Resistance: Offers excellent mechanical strength, preventing support collapse during large-scale complex prints.
Smooth Surface Finish: Leaves negligible contact marks on lower layers, minimizing post-processing and manual finishing.
Colorant-Free Formulation: Pure material formulation prevents pigment bleeding or residue staining on target models.
Easy & Reliable Printability: Features consistent diameter tolerance and low-warping characteristics for smooth, hassle-free extrusion.
Technical Datasheet
Melt Temperature: ~240°C (ISO 11357)
Melt Flow Rate (MFR): 5–7 g/10min¹ (ISO 1133)
Heat Deflection Temperature (HDT): 97°C² (ISO 75)
Vicat Softening Temperature (VST): 103°C³ (ISO 306)
Density: 1.04 g/cm³ (ISO 1183)
Odor: Low odor
Solubility: Insoluble in water (Soluble in D-Limonene)
Note: ¹ Test conditions: T= 200℃; m= 5kg. ² Test conditions: 0.45MPa; 120℃/h. ³ Test conditions: 10N; 120℃/h.
Applications
Certificates
