THE K12™ PEI 9085

Color
Natural
Weight
Diameter
Description
  • Aerospace-Grade Reliability
  • Exceptional Heat Resistance
  • High Mechanical Strength
  • Superior Flame Resistance
  • Broad Chemical Resistance
  • High Toughness & Durability
  • Low Molding Temperature & Flowability



Temperature Resistance Strength Toughness Rigidity Ease of Printing Z-axis Strength

Suggested Printing Parameters

Nozzle temperature 340 ~ 370℃
Bed temperature 140 ~ 220℃
Chamber temperature 90 ~ 200℃
Bed modification High temperature glue
Active cooling fan OFF
Layer height 0.2mm
Shell thickness ≥ 0.8mm
Print speed 30~60mm/s
Settings are based on a 0.4mm nozzle.

Technical Data Sheet (TDS)

Material Properties Typical Value Test Method
Melt temperature (HDT)² ~300℃ ISO 11357
Melt flow rate (MFR)¹ 60~70g/10min ISO 1133
Heat deflection temperature (HDT)² 168℃ ISO 75
Vicat softening temperature (VST)³ 181℃ ISO 306
Density 1.28g/cm³ ISO 1183
Odor Odorless /
Solubility Insoluble in water /

1. Test conditions: T= 365℃; m= 5kg.

2. Test conditions: 0.45MPa; 120℃/h.

3. Test conditions: 10N; 120℃/h.

Download TDS
Download Brochure

THE K12™ PEI 9085 has passed the following certifications: RoHS China, California Proposition 65(CP65), TSCA, EU RoHS, UK RoHS, REACH SVHC.
