THE K11™ PEEK GF10

Color
Natural
Weight
Diameter
Description
  • Glass Fiber Reinforcement
  • Lightweight Metal Replacement
  • High Strength & Rigidity
  • Higher Density & Toughness
  • Excellent Heat Resistance
  • Broad Chemical Resistance
  • Inherent Flame Resistance



Temperature Resistance Strength Toughness Rigidity Ease of Printing Z-axis Strength

Suggested Printing Parameters

Nozzle temperature 400 ~ 450℃
Bed temperature 110 ~ 220℃
Chamber temperature 80 ~ 220℃
Bed modification NO & High temperature glue
Active cooling fan OFF
Layer height 0.2mm
Shell thickness ≥ 0.8mm
Print speed 30~60mm/s
Settings are based on a 0.4mm nozzle.

Technical Data Sheet (TDS)

Material Properties Typical Value Test Method
Melt temperature (HDT)² ~340℃ ISO 11357
Melt flow rate (MFR)¹ 10~15g/10min ISO 1133
Heat deflection temperature (HDT)² 202℃ ISO 75
Vicat softening temperature (VST)³ / ISO 306
Density 1.28g/cm³ ISO 1183
Odor Odorless /
Solubility Insoluble in water /

1. Test conditions: T= 380℃; m= 5kg.

2. Test conditions: 0.45MPa; 120℃/h.

3. Test conditions: 10N; 120℃/h.

Download TDS
Download Brochure

THE K11™ PEEK GF10 has passed the following certifications: RoHS China, California Proposition 65(CP65), TSCA, EU RoHS, UK RoHS, REACH SVHC.
