THE K11™ PEEK CF10

  • TOUGHNESS
  • STRENGTH
  • HEAT RESISTANCE
  • Printability
  • Rigidity
  • Z-axis strength
CHOOSE DIAMETER
  • 1.75mm
CHOOSE WEIGHT
  • 1kg
  • 0.5kg
CHOOSE COLORS
COLOR:
  • Black

Feature Introduction:

THE K11™ PEEK CF10 is a carbon fiber-reinforced PEEK material with high strength and rigidity, and resistance to high temperatures. Instead of metal parts in many applications, printed products are lightweight and strong with high-quality interlayer adhesion and smooth surface, which are less prone to warpage.

Basic Physical Properties:

THE K11™ PEEK CF10 Printed copy (horizontal printing of sample, 100% linear filling) Injection molded parts Test standards
Density (g/cm3) 1.33 ISO 1183
Melt index (g/10min) * 1 10-15 ISO 1133
Thermal deformation temperature (℃) * 2 200   ISO 75
Vicat softening temperature (℃) * 3 95   ISO 306
Tensile strength (MPa) 85-90   ISO 527
Tensile elongation at break (%) 3-6
Bending strength (MPa) 120-130   ISO 178
Bending modulus (MPa) 5000-6000
Notched impact strength (KJ/m2) 30-35   ISO 179
Notch impact strength (KJ/m2) 8-12

*1. Test condition: temperature (T)=380 ℃; Mass (m)=5kg.
*2. Test condition: bending stress=0.45MPa; Heating rate=120 ℃/h.
*3. Test condition: load=10N; Heating rate=120 ℃/h.
