THE K10™ PC
Color
Black
Weight
Diameter
THE K10™ PC is a high heat-resistance PC material for industrial FDM/FFF 3D printers. With mechanical properties comparable to normal PC materials, its softening temperature is increased by more than 30°C, which is close to PEI, but easier to print than PEI.
Suggested Printing Parameters
| Nozzle temperature | 310 ~ 350℃ |
| Bed temperature | 140 ~ 180℃ |
| Chamber temperature | 80 ~ 150℃ |
| Bed modification | NO & High temperature glue |
| Active cooling fan | OFF% |
| Layer height | 0.2mm |
| Shell thickness | ≥ 0.8mm |
| Print speed | 30-60mm/s |
Technical Data Sheet (TDS)
| Material Properties | Typical Value | Test Method |
|---|---|---|
| Melt temperature (HDT)² | ~280℃ | ISO 11357 |
| Melt flow rate (MFR)¹ | 30~35g/10min | ISO 1133 |
| Heat deflection temperature (HDT)² | 163℃ | ISO 75 |
| Vicat softening temperature (VST)³ | 176℃ | ISO 306 |
| Density | 1.18~1.20g/cm³ | ISO 1183 |
| Odor | Odorless | / |
| Solubility | Insoluble in water | / |
